| PHYSICAL CHARACTERISTICS |
Dimension
|
Direct Thermal :
8.69 in. L x 6.98 in. W x 5.93 in. H
220. 8 mm L x 177.5 mm W x 150.7 mm H
|
Thermal Transfer Roll :
10.5 in. L x 8.0 in. W x 7.44 in. H
267 mm L x 202 mm W x 189 mm H |
Thermal Transfer Cartridge :
10.0 in. L x 8.0 in. W x 7.0 in. H
254 mm L x 202 mm W x 177 mm H |
Weight
|
Direct Thermal: 2.98 Ibs./1.35 kg |
| Thermal Transfer Roll: 4.52 Ibs./2.05 kg |
| Thermal Transfer Cartridge: 5.0 Ibs./2.3 kg |
| PRINTER SPECIFICATIONS |
| Operating System |
Link-OS® |
| Resolution |
203 dpi/8 dots per mm
300 dpi/12 dots per mm (Optional) |
| Memory |
512 MB Flash; 256 MB SDRAM
64 MB user available non-volatile memory
8 MB user available SDRAM
|
| Maximum Print Width |
4.09 in./104 mm for 203 dpi
4.27 in./108 mm for 300 dpi
Cartridge: 4.09 in./104 mm for 203 and 300 dpi |
| Maximum Print Speed |
6 in. /152 mm per second (203 dpi)
4 in. /102 mm per second (300 dpi) |
| Media Sensors |
Full width, moveable reflective/black mark sensor;
multi-position transmissive/gap sensor |
| Firmware |
ZPL 11; EPL 2; XML; ZBI; PDF Direct |
| MEDIA AND RIBBON CHARACTERISTICS |
| Label Length |
Maximum: 39.0 in./991mm
Minimum: 0.25 in./6.4 mm |
| Media Width |
Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm
Thermal Transfer Roll: 0.585 in./15 mm to 4.41 in./
112 mm
Thermal Transfer Cartridge: 0.585 in./15 mm to
4.65 in./118 mm |
| Media Roll Size |
Maximum outer diameter: 5.00 in./127 mm
Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in.
(25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm)
and 3.0 in. (76.2 mm) using optional adapters |
| Media Thickness |
0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max. |
| Media Types |
Roll-fed or fan-fold, die cut or continuous with or
without black mark, tag stock, continuous receipt
paper, and wristbands |
| Ribbon Outside Diameter |
2.6 in. /66 mm (300 m); 1.34 in./34 mm (74 m) |
| MEDIA AND RIBBON CHARACTERISTICS (CONT.) |
| Ribbon Standard Length |
Roll: 984 ft. (300 m); 243 ft. (74 m)
Cartridge: 243 ft. (74 m) |
| Ribbon Ratio |
1:4 ribbon to media (300 m)
1:1 ribbon to media (74 m) |
| Ribbon Width |
Roll: 1.33 in./33.8 mm - 4.3 in./109.2 mm
Cartridge: 4.3 in./109.2 mm |
| Ribbon Core I.D. |
300 meter ribbon 1 in./25.4 mm
74 meter ribbon 0.5 in./12.7 mm |
| OPERATING CHARACTERISTICS |
| Operating Temp. |
40° to 105° F/4.4° to 41° C |
| Storage Temp. |
-40° to 140° F/-40° to 60° C |
| Operating Humidity |
10% to 90% non-condensing |
| Storage Humidity |
5% to 95% non-condensing |
| Electrical |
Auto-detectable (PFC Compliant) 100-240VAC,
50-60Hz; ENERGY STAR certified; Energy Efficiency
Level VI certified; optional 2750 mAh battery;
Healthcare models include IEC60601-1 certified
power supply |
| OPTIONS AND ACCESSORIES |
| Media Handling |
Dispenser/Peeler: label peel and present with label
present sensor (field installable)
Cutter (field installable) |
| Communications |
Field installable: Ethernet 10/100, 802.11ac Wi-Fi
and Bluetooth 4.1 (dual radio); Serial RS-232 auto-
sensing, DB-9
Factory installed: Ethernet 10/100, 802.11ac Wi-Fi
and Bluetooth 4.1 (dual radio) |
| Battery |
Provides power to the printer to support a full shift
of printing at maximum print speed; supports all
connectivity and media handling options |
| Carrying case |
Carrying case with shoulder strap and handles
makes it easy to bring your desktop printer and
battery to the point of application |
| Keyboard Display Unit |
Zebra Keyboard Display Unit (ZKDU) unit for stand-
alone printing solutions |
| Media Locking Cabinet |
Mechanical lock with 2 keys; Kensington® lock slot; available on ZD420d Healthcare only |
| Mounting Plate |
Secure ZD Series printers to countertops or shelves |
| Enclosed Power Supply |
Attached power supply accessory for cord-free
installation |
| FONTS/GRAPHICS/SYMBOLOGIES |
| Barcode Ratios |
2:1 and 3:1 |
| 1D Barcodes |
Code 11. Code 39. Code 93. Code 128, ISBT-128.
UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or
5-digit extensions, Plessey, Postnet, Standard 2-of-
5, Industrial 2-of-5, Interleaved 2-of-5, Logmars,
MSI, Codabar and Planet Code |
| 2D Barcodes |
Codablock, PDF417, Code 49, DataMatrix,
MaxiCode, QR Code, MicroPDF, Aztec |
| Fonts and Graphics |
16 resident expandable ZPL II bitmap fonts,
two resident scalable ZPL fonts, five resident
expandable EPL2 fonts, native open-type font
support, Unicode compliant. China units include
SimSun simplified Chinese font |
