| Dimensions |
Wrist (device):
2.44 in. L x 2.32 in. W x 0.71 in. D
62 mm L x 59 mm W x 18 mm D
Wrist (with mount):
2.91 in. L x 2.51 in. W x 0.751 in. D
74 mm L x 64 mm W x 19 mm D
Converged:
2.52 in. L x 2.44 in. W x 1.10 in. D
64 mm L x 62 mm W x 28 mm D
|
| Weight |
Wrist (device): 2.47 oz./70 g;
Wrist (with mount): 3.95 oz./112 g
Converged: 4.73 oz./134 g |
| Display |
2 in. AMOLED 460 x 460 color display; optically bonded to touch panel |
| Imager Window |
Corning® Gorilla® Glass |
| Touch Panel |
Capacitive touch panel; fingertip and glove support; Corning® Gorilla® Glass |
| Power |
Standard (Wrist): 3.08 Watt Hours; 800 mAh
High Capacity (Converged): 5 Watt Hours; 1300 mAh
PowerPrecision; Hot Swap (2 minutes, memory persistent) |
| Network Connections |
USB 2.0 High Speed (host and client),
WLAN and Bluetooth |
| Notifications |
Audible tone; charge LED; OS notification LED;
multi-color Application LEDs (2); haptic feedback |
| Voice and Audio |
Speaker (90dBA); internal mic; PTT ready; Bluetooth headset support |
| Buttons |
Wrist: 4 buttons (programmable)
Converged: trigger; 2 buttons (programmable) |
| Interfaces |
Docking contacts; Via interface cables: USB-C (USB 2.0) host/client and charging |
Scanner Performance
|
|
| Optical Resolution |
1280 x 800 pixels |
| Roll |
360° |
| Pitch |
±60° |
| Skew |
±60° |
| Aiming Element |
655 nm Laser |
| Illumination Element |
1 Hyper Red 660 nm LED or 1 Warm-White LED |
| Field of View |
Horizontal: 48°, Vertical: 30° |
Ambient Light Immunity (from total darkness)
|
Maximum 107,639 lux (direct sunlight)
|
Supported 1D Symbologies
|
Code 39, Code 128, Code 93, Codebar/NW7, Code 11, MSI, UPC/EAN, I 2 of 5, Korean 3 of 5, GSI DataBar, Base 32 (Italian Pharma)
|
Supported 2D Symbologies
|
PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes
|
Supported OCR Symbologies
|
OCR-A, OCR-B
|
Scan Triggering
|
Manual ambidextrous trigger or automatic via Proximity Sensor technology |
| Performance Characteristics |
|
| CPU |
Snapdragon Wear™ 4100 Platform/SDW429w,
quad-core, 2.0 GHZ |
| Operating System |
Android 11 AOSP |
| Memory |
1 GB RAM/8 GB Flash |
| User Environment |
|
| Operating Temperature |
14° F to 122° F/-10° C to +50° C |
| Storage Temperature |
-40° F to 158° F/-40° C to +70° C |
Humidity
|
5% - 95% non condensing
|
Drop Specification
|
Wrist: 4 ft./1.2 m drop to concrete per MIL-STD 810G across operating temperature
Converged: 6 ft./1.8 m drop to tile over concrete per MIL-STD 810G across operating temperature
|
Tumble Specification
|
Wrist: 1,000 tumbles @ 1.6 ft./0.5 m
Converged: 2,000 tumbles @ 1.6 ft./0.5 m Meets and exceeds IEC tumble specifications
|
Sealing
|
IP65
|
Vibration
|
4 g’s PK Sine, 5hz to 2khz, 1 hour duration per axis; 0.04 g2/Hz Random (20 Hz to 2 kHz), 1 hour duration per axis. |
Electrostatic Discharge (ESD)
|
+/-15 kV air discharge, +/-8 kV direct/indirect discharge |
Interactive Sensor Technology (IST)
|
|
Light Sensor
|
Automatically adjusts display backlight brightness
|
Motion Sensor
|
6-axis accelerometer with MEMS Gyro
|
| Data Capture |
|
| Scanning |
Converged: SE4770 1D/2D standard range omni-directional imager
Wrist: 13 MP camera with flash, or no data capture option
|
| Camera |
13 MP with Flash (Wrist only) |
| NFC |
Tap to Pair, ISO 14443 Type A and B, Felica and ISO 15693 cards, and Card Emulation via Host (HCE) support |
| Scan Triggering |
Manual or automatic via proximity sensor technology |
| Wireless LAN |
|
| Radio |
IEEE 802.11 a/b/g/n/ac/d/h/i/r; Wi-Fi™ certified; IPv4, IPv6, 1x1 SISO |
| Data Rates |
2.4 GHz: 802.11b/g/n/ac — 20 MHz, 40 MHz — up to 200 Mbps
5 GHz: 802.11a/g/n/ac — 20 MHz, 40 MHz, 80 MHz — up to 433 Mbps
|
| Operating Channels |
Channel 1-13 (2412-2472 MHz); Channel 36-165 (5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency |
| Security and Encryption |
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, EAP-PWD |
| Certifications |
WFA (802.11n, 80211ac, WPA2-Personal, WPA3-Personal, WPA2-Enterprise, PMF)
|
| Fast Roam |
PMKID caching; 802.11r (Over-The-Air); OKC
|
| Wireless PAN |
|
| Bluetooth |
Bluetooth 4.2; Bluetooth Low Energy (BLE) support; Class 1 |
