| Physical Characteristics | |
| Dimensions | RFD9030: 7.4 x 3.2 x 6.8 in./189 x 83.4 x 173 mm
RFD9090: 9.8 x 3.8 x 6.8 in./248 x 96.3 x 173 mm |
| Weight | RFD9030 with SE4750MR: 25 oz./714 grams
RFD9030 with SE4850: 26.5 oz./751 grams
RFD9090 with SE4750MR: 26.8 oz./759 grams
RFD9090 with SE4850: 28.2 oz./799 grams |
| Power | Quick-Release, PowerPrecision+ Li-Ion 7,000
mAh battery |
| Notification | Bluetooth Status LED
Wi-Fi Status LED
Decode LEDs
Battery Status LED
Beeper |
| User Input | Tri-Function User Programmable Trigger |
| RFID Performance | |
| Standards Supported | EPC Class 1 Gen 2; EPC Gen2 V2 |
| RFID Engine | Zebra Proprietary Radio Technology |
| Fastest Read Rate | 1,300+ tags/sec |
| Nominal Read Range | RFD9030: ~22 ft./~6.7 m
RFD9090: ~75 ft./~22.9 m |
Frequency Range and
RF System Output | RFD9030:
US: 902–928 MHz; 0–30 dBm (EIRP)
EU: 865–868 MHz; 0–30 dBm (EIRP)
916.3, 917.5, and 918.7 MHz; 0–30 dBm (EIRP)
Japan: 916–921 MHz (w LBT), 0–30 dBm (EIRP) RFD9090:
US: 902–928 MHz; 5.5–35.5dBm (EIRP)
EU: 865–868 MHz; 5.5–35.5dBm (EIRP)
916.3, 917.5, and 918.7 MHz; 5.5–35.5dBm (EIRP)
Japan: 916–921 MHz (w LBT), 5.5–35.5dBm (EIRP) |
| Wireless LAN | |
| Radio | IEEE 802.11 ax/ac/a/b/g/n 2X2, MU-MIMO, IPv4 |
| Data Rate | 5 GHz PHY data rates up to 1.2 Gbps;
2.4 GHz PHY data rates up to 458 Mbps |
| Operating Channels | Channel 1–14: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14;
Channel 36–196: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165, 172, 183, 184, 185, 187, 188, 189, 192, 196;
Channel Bandwidth: 20, 40, 80 MHz |
| Security and Encryption | TKIP, AES, EAP-TLS, EAP-PEAPv2, EAP-TTLS, EAP-FAST, PEAP, LEAP |
| SE4750MR Standard Range Imager | |
| Sensor Resolution | 1280 x 960 pixels |
| Field of View | 31° horizontal, 23° vertical |
Skew Tolerance
| ±60° |
Pitch Tolerance
| ±60° |
Roll Tolerance
| 360° |
Focal Distance
| 14.2 in./36.1 cm from front of engine |
Aiming LED
| 655 nm laser |
Illumination
| 2X warm white LEDs |
| SE4850 Extended Range Imager | |
Sensor ResolutionSensor Resolution
| 1280 x 800 pixels |
| Field of View | Far: 12° horizontal, 7.6° vertical
Near: 32° horizontal, 20° vertical |
Skew Tolerance
| ±60° |
Pitch Tolerance
| ±60° |
Roll Tolerance
| 360° |
Focal Distance
| Far: 15–350 in./38.1–889 cm from front of engine
Near: 11 in./27.8 cm from front of engine |
Aiming Element
| 655 nm laser |
Illumination Element
| Hyper red 660 nm LED |
Minimum Print Contrast
| 25% |
User Environment
| |
Drop Specification
| Multiple 6 ft./1.8 m drops to concrete |
Tumble Specification
| 500 cycles (1,000 drops, 1.6 ft./0.5 m) at room temperature |
Operating Temperature
| -4°F to 131°F/-20°C to 55°C |
Storage Temperature
| -40°F to 158°F/-40°C to 70°C |
Humidity
| 5–85% non-condensing |
Electrostatic
Discharge
| ±15 kV air discharge
±8 kV direct discharge
±8 kVdc indirect discharge |
Sealing
| IP65 (spray) and IP67 (submersion) |
Accessories
| |
Cradles and Charging
| Cable Cup
USB Wall Brick for Cable Cup
1-Slot Charging Cradle
1-Slot Charging and USB Cradle
Multi-Slot Charging Cradle
Multi-Slot Charging and Ethernet Cradle
4-Slot Battery Toaster |
Other Accessories
| eConnex™ Adaptors for Supported Zebra Mobile Computers
Battery Locking Foot
Belt Holster |
Communication
| |
Host Connection
| Electronic 8-Pin Connection (eConnex™)
Bluetooth 5.3
USB Cable Cup |
Host Computer
| Zebra mobile computers and tablets
3rd-party smartphones and tablets
Windows-based PCs |
Mobile Computer Adaptors
| eConnex, Bluetooth, OtterBox uniVERSE
Case System |
Bluetooth Profiles Supported
| SPP Profile
HID Profile
Apple iAP2/MFi |
Remote Management
| Wi-Fi 6
Ethernet Cradles
Via Attached Host Device |
| Regulatory | |
EMI/EMC
| FCC Part 15 Subpart B Class B; ICES 003 Class B; EN 301 489-1; EN 301 489-3; EN 55024;
EN 55032 Class B |
Electrical Safety
| IEC 62368-1 (ed.2)
UL 62368-1, second edition, CAN/CSA-C22.2
No. 62368-1-14 |
RF Exposure
| EU: EN 50364, EN 62369-1, EN 50566, EN 62311;
USA: FCC Part 2. 1093 OET Bulletin 65 Supplement ‘C’; Canada: RSS-102 |
RFID
| EU EN 302 208, FCC Part 15 Subpart C;
Canada: RSS-247 |
LED Classification
| IEC 62471 |
