| Specifications |
|
| Physical Characteristics |
|
| Dimensions |
2.95 in. H x 8.58 in. L x 3.09 in. W
7.50 cm H x 21.80 cm L x 7.86 cm |
| Weight |
290g |
| Display |
4.0 inch capacitive; WVGA; color |
| Touch Panel |
Corning Gorilla Glass touch panel with air gap |
| Imager Window |
Corning Gorilla Glass |
| Interface/Communications |
USB 2.0 Client Cable for device maintenance |
| Voice |
Push-to-Talk (PTT) voice support via internal speaker; Zebra Workforce Connect PTT Pro (optional) |
| Audio |
Speaker; One (1) microphone (Plus configuration) |
| Buttons |
1 dedicated scan button |
| Performance Characteristics |
|
| Processor |
Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz |
| Operating System |
Upgradeable to Android 14 |
| Memory |
Base and Plus Configurations: 4GB RAM/16GB Flash |
| Power |
PowerPrecision+ 3500 mAh capacity Li Ion rechargable battery |
| Security |
Verified Boot; Secure Boot |
| User Environment |
|
| Operating Temp. |
14° F to 122° F/-10° C to 50° C |
| Storage Temp. |
-4° F to 158° F/-20° C to 70° C
|
Humidity
|
Relative Humidity 5% to 95% non-condensing
|
Drop Specification
|
Multiple 4 ft./1.2 m drops to concrete over the entire operating temperature range
|
Tumble Specification
|
1,000 1.64 ft./0.5 m tumbles at room temperature
|
Vibration
|
2g peak, 5 Hz to 2 kHz, 1 hour duration per axis |
Thermal Shock
|
-4° to 158° F/-20° to 70° C
|
Electrostatic Discharge (ESD)
|
(+/-15kV) air, (+/-8kV) contact discharge
|
Data Capture
|
|
Scanning
|
Base model: SE2100 1D/2D imager
Plus model: SE4710 1D/2D imager + Digimarc support
|
Light Source
|
Base model: White LED Illumination
Plus model: Red LED Illumination with LED dot aim pattern
|
Camera — Front Facing
|
Plus model only: 5 MP fixed focus |
| Interactive Sensor Technology |
Plus configurations only: 3-axis accelerometer, gyroscope, scanning proximity sensor |
WLAN
|
|
Radio
|
IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v3/w; Wi-Fi™ certified; IPv4, IPv6, 2x2 MU-MIMO
|
Data Rates
|
5GHz: 802.11a/n/ac — up to 866.7 Mbps
2.4GHz: 802.11b/g/n — up to 300 Mbps
|
Operating Channels (depending on Regulatory)
|
Channel 1-13 (2412-2472 MHz); Channel 36-165
(5180-5825 MHz)
Channel Bandwidth: 20, 40, 80 MHz
Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency
|
Security and Encryption
|
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA/WPA2 Enterprise (TKIP and AES)
— EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC and LEAP. EAP-PWD
|
Certifications
|
WFA (802.11n, WMM-PS, 801.11ac, PMF)
|
Fast Roam
|
PMKID caching; Cisco CCKM; 802.11r; OKC
|
| WPAN |
Class 2, Bluetooth v5.0, Bluetooth Low Energy (BLE) |
Locationing
|
Supports Zebra’s Device Tracker; SmartLens, SNAP and MPact Supports Visual Light Communication (VLC)
|
Warranty
|
Subject to the terms of Zebra’s hardware warranty statement, the PS20 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, please visit:
www.zebra.com/warranty
|
Recommended Services
|
Zebra OneCare Essential and Select Support Services
Zebra OneCare Visibility Services (OVS, AVS)
|
Footnotes
|
For details related to Common Criteria support, please visit:
www.zebra.com/commoncriteria
|
Mobility DNA Software
|
Mobility DNA solutions help you get more value out of our mobile computers by adding functionality as well as simplifying deployment and management of our mobile devices. For more information on these Zebra-only features, please visit
www.zebra.com/mobilitydna
Mobility DNA is available on Android only. Features may vary by model and a Support Contract may be required. To learn what solutions are supported, please visit:
https://developer.zebra.com/mobilitydna
|
