| Physical Characteristics |
| Dimensions | 6.5 in. H x 2.6 in. W x 3.9 in. D
16.5 cm H x 6.7 cm W x 9.8 cm D |
| Weight | 5.7 oz. / 161.9 g |
| Input Voltage Range | 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply |
| Operating Current at Nominal Voltage (5.0V) | 375 mA (typical) |
| Standby Current (Idle) at Nominal Voltage (5.0V) | 150 mA (typical) |
| Color | Healthcare White |
| Supported Host Interfaces | USB, RS232, TGCS (IBM) 46xx over RS485 |
| Keyboard Support | Supports over 90 international keyboards |
| User Indicators | Direct Decode Indicator, Good Decode LEDs, rear view LEDs, beeper (ajdustable tone and volume), haptic/vibration |
| Performance Characteristics |
| Light Source | Aiming Pattern; circular 528nm true green LED |
| Illumination | (2) warm white LED’s |
| Imager Field or View | 35° H x 22° V nominalinal |
| Image Sensor | 1280 x 800 pixels |
| Minimum Print Contrast | 15% minimum reflective difference |
| Skew Tolerance | +/- 60° |
| Pitch Tolerance | +/- 60° |
| Roll Tolerance | 0° - 360° |
| Imaging Characteristics |
| Graphics Format Support | Images can be exported as Bitmap, JPEG or TIFF |
| Environmental |
| Operating Temperature | 32.0° to 122.0° F / 0.0° to 50.0° C |
| Storage Temperature | -40.0° to 158.0° F / -40.0° to 70.0° C |
| Humidity | 5% to 95% RH, non-condensing |
| Drop Specification | Designed to withstand multiple drops at 6.0 ft./1.8 m to concrete |
| Tumble Specification | Designed to withstand 2,000 tumbles in 1.5 ft./0.5 m tumbler |
| Environmental Sealing | IP52 |
| Approved Cleaners | Disinfectant Ready. Refer to the product reference guide for the complete list of approved cleaners. |
| Electrostatic Discharge (ESD) | ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect |
| Ambient Light Immunity | 0 to 10,000 foot candles/0 to 107,000 Lux |
| Regulatory |
| Environmental | 2011/65/EU and EN 50581:2012 and EN IEC 63000:2018 |
| Electrical Safety | UL 60950-1, second edition, CAN/CSA-C22.2
No. 60950-1-07. EN 60950-1:2006/A2:2013
IEC 60950-1:2005/A2:2013
IEC 62368-1 (ed.2); EN 62368-1:201 |
| LED Safety | IEC 62471:2006 (Ed.1.0); EN 62471:2008 |
| EMI/RFI | FCC: 47 CFR Part 15, Subpart B, Class B
ICES-003 Issue 6, Class B
EN 55032, Class B
EN 55024
EN 55035
EN 60601-1-2:2015
IEC 60601-1-2:2014 |
| Accessories | Gooseneck Intellistand, Cup |
| Symbol Decode Capability |
| 1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro Han Xin, Postal Codes, SecurPharm |
| Minimum Element Resolution | Code 39 - 2.0 mil
DataMatrix - 4.0 mil |
| Symbology/Resolution | Near/Far |
| Code 39: 3 mil | 1.3 in./3.3 cm to 6.0 in./15.2 cm |
| Code 39: 5 mil | 0 .1 in./0.3 cm to 11.5 in./29.2 cm |
| Code 39: 20 mil | 0.6 in./1.5 cm to 29.0 in./73.7 cm |
| Code 128: 5 mil | 1.7 in./4.3 cm to 5.0 in./12.7 cm |
| PDF 417: 6.7 mil | 0.6 in./1.5 cm to 9.3 in./23.6 cm |
| UPC: 13 mil (100%) | 0 in./0 cm to 18.0 in./45.7 cm |
| DataMatrix: 10mil | 0.2 in./0.5 cm to 9.5 in./24.1 cm |
| QR: 20mil | 0 in./0 cm to 13.5 in./34.3 cm |
