| Print Method |
Thermal Transfer / Direct Thermal |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
6IPS (150 mm/s) |
| Print Width |
4.09” (104 mm) |
| Print Length |
Min. 0.16” (4 mm)** ; Max. 100” (2540 mm) |
| Processor |
32 Bit RISC CPU |
| Memory |
8MB Flash (4MB for user storage) / 16MB SDRAM |
| Sensor Type |
Adjustable reflective sensor and transmissive sensor, left aligned |
| Media |
Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: Standard: 1” (25.4 mm) Min. - 4.64” (118 mm) Max.
With Cutter: 4.61” (117 mm) Max.
With Dispenser / Rewinder: 4.64” (118 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.
Label roll diameter: Max. 8” (203.2 mm) with 3" (76.2 mm) core / Max. 6” (152.4 mm) with 1.5" (38.1 mm) core
Core diameter: 1.5” (38.1 mm) - 3” (76.2 mm) |
| Ribbon |
Types: Wax, wax/resin, resin
Length: 1471’ (450 m)
Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max
Ribbon roll diameter.: 2.99” (76 mm)
Core diameter: 1” (25.4 mm) |
| Printer Language |
EZPL, GEPL, GZPL auto switch |
| Software |
Label design software: QLabel-IV / GoLabel (for EZPL only)
Driver & DLL: Windows 2000, XP, Vista, 7,8, Windows Server 2003 & 2008 |
| Resident Fonts |
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable |
| Download Fonts |
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable |
| Barcodes |
1-D Bar codes:
Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars,
Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight,
Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-D Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code |
| Code Pages |
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode UTF8、UTF16BE、UTF16LE |
| Graphics |
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
| Interfaces |
Serial port: RS-232 (DB-9)
USB port
Ethernet 10/100Mbps |
| Control Panel |
Three mono-color LED indicators: Power on, Ribbon out, Media out
Control keys: FEED, PAUSE and CANCEL
Calibration button |
| Power |
Auto Switching 100-240VAC, 50-60Hz |
| Real Time Clock |
Standard |
| Environment |
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C) |
| Humidity |
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing. |
| Agency Approvals |
CE(EMC), FCC Class A, CB, cUL, CCC |
| Dimension |
Length: 20.15” (512 mm)
Height:11.45” (291 mm)
Width: 10.78” (274 mm) |
| Weight |
33 lbs (15 Kg), excluding consumables |
| Options |
Cutter Module
Label Dispenser + Internal Rewinder
Parallel Port(IEEE1284)
Applicator Interface (1 input, 3 outputs, power 500mA @ 5V)
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder |
| Note |
* Specifications are subject to change without notice. All company and/or product names are trademarks and/or registered trademarks of their respective owners.
** Minimum print height and maximum print speed specification compliance can be dependent on non-standard material variables such as label type, thickness, spacing, liner construction, etc. GoDEX is pleased to test non-standard materials for minimum print height and maximum print speed capability. |
