| Print head | |
| Material feed | left-aligned | left-aligned |
| Printing method Thermal transfer |  | |
| Printing method Thermal direct | - | - |
| Printable resolution dpi | 300 | 300 |
| Print speed up to mm/s | 125 | 125 |
| Print width up to mm | 105.6 | 162.6 |
| Material |
Roll: Paper, cardboard, plastics such as
Roll: PET, PE, PP, PI, PVC, PU, acrylate, Tyvec | | |
| Labels Width mm | 20 - 116 | 46 - 176 |
| Labels Height mm | 20 - 2,000 | 20 - 2,000 |
| Labels Thickness mm | 0.05 - 0.2 | 0.05 - 0.2 |
| Liner material Width mm | 24 - 120 | 50 - 180 |
| Roll Outside diameter up to mm | 300 | 300 |
| Roll Core diameter mm | 76 - 100 |
| Roll Winding | outside or inside |
| Ribbon |
| Ink side | outside or inside |
| Roll diameter up to mm | 72 |
| Core diameter mm | 25 |
| Variable length up to m | 360 |
| Width up to mm | 114 | 165 |
| Printer sizes and weights |
| Width x Height x Depth mm | 248 x 395x 554 | 358 x 395 x 554 |
| Weight kg | 22 | 24 |
| Label sensor with position indication |
| Gap sensor for | labels, punch marks or print marks in transparent materials and end of material |
| Reflective sensor from below or top (option) for | print marks in not transparent materials and end of material |
| Distance sensor to locating edge mm | 5 - 53 |
| Electronics |
| Processor 32 bit clock rate MHz | 266 |
| Main storage (RAM) MB | 64 |
| Data storage (IFFS) MB Flash | 8 |
| Slot for CompactFlashType I | |
| Slot for WLAN card | |
| Battery buffer for real-time clock | |
| Acoustic error signal | |
| Interfaces |
| USB 2.0 Hi-speed slave to connect a PC | |
| Ethernet 10 / 100 Mbit/s | LPD, RawIP-Printing, FTP, DHCP, HTTP, SMTP, SNMP, TIME, Zeroconf, mDNS, SOAP |
| Periphery connection | |
| WLAN 802.11b/g WEP/WPA-PSK (TKIP) |  |
| 2 x USB host for | Service Key, USB memory stick, keyboard, barcode scanner, external operation panel |
| Operating data |
| Power supply | 100 - 240 VAC ~ 50/60 Hz, PFC |
| Power consumption W | 100 - 300 depending from the type of device |
| Temperature / humidity Operation | 5 - 40°C / 10 - 85% not condensing |
| Temperature / humidity Storage | 0 - 60°C / 20 - 80% not condensing |
| Temperature / humidity Transport | – 25 - 60°C / 20 - 80% not condensing |
| Approvals | CE, FCC, CB, cULus, CCC |
