| Material feed | centered |
| Printing method: Thermal transfer |  | | | |
| Printing method: Thermal direct | | | | |
| Printable resolution dpi | 203 | 300 | 203 | 300 | 300 | 300 |
| Print speed up to mm/s | 150 | 150 | 150 | 150 | 150 | 150 |
| Print width up to mm | 108 | 105.7 | 108 | 105.7 | 105.7 | 105.7 |
| Start of printing Distance to locating edge mm | centered |
| Material |
Paper, cardboard,
plastics PET, PE, PP, PI, PVC, PU, acrylate, Tyvec | | | | |
| Shrink tubes ready-for-use | | | - | - |
| Shrink tubes continuous, pressed | | | - | - |
| Textile tapes | | | | |
| Packing on rolls, reels | | | | |
| Packing Fanfold |  | | - | - |
| Packing Roll diameter up to mm | 152 | 203 | 152 | 203 |
| Packing Core diameter mm | 38.1 - 76 |
| Packing Winding | outside or inside |
| Labels Width single-lane mm | 10 - 116 |
| Labels Width multi-lane mm | 5 - 116 |
| Labels Height excl. label backfeed from mm | 5 |
| LabelsHeight incl. label backfeed from mm | 12 |
| Labels Thickness mm | 0.05 - 0.6 |
| Liner material Width mm | 25 - 120 |
| Liner material Thickness mm | 0.05 - 0.16 |
| Continuous material Width mm | 5 - 120 |
| Continuous material Thickness mm | 0.05 - 0.5 |
| Continuous material Weight (cardboard) up to g/m2 | 180 |
| Shrink tubes Width ready-for-use up to mm | 120 |
| Shrink tubes Width continuous, pressed mm | 5 - 85 |
| Shrink tubes Thickness up to mm | 1.1 |
| Ribbon2) Ink side | outside or inside |
| Ribbon Roll diameter up to mm | 72 |
| Ribbon Core diameter mm | 25.4 |
| Ribbon Variable length bup to m | 360 |
| Ribbon Width mm | 25 –114 |
| Printer sizes and weights |
| Width x Height x Depth mm | 253 x 191 x 322 | 264 x 247 x 412 | 253 x 191 x 322 | 264 x 247 x 412 |
| Weight kg | 4 | 5 | 4 | 5 |
| Label sensor with position indication |
| Gap sensor for | labels or punch marks and end of material, print marks on transparant materials |
| Reflective sensor from below or top for | labels and end of material, print marks on non-transparent materials |
| Distance from center to locating edge centered mm | 0 - 58 |
| Material passage up to mm | 4 |
| Electronics | |
| Processor 32 bit clock rate MHz | 800 |
| Main storage (RAM) MB | 256 |
| Data storage (IFFS) MB | 50 |
| Slot for SD memory card (SDHC, SDXC) up to GB | 512 |
| Battery for time and date, real-time clock |  |
| Data memory when power is turned off (e.g. serial numbers) | |
| Interfaces | |
| RS232C 1,200 to 230,400 baud/8 bit | |
| USB 2.0 Hi-speed device to connect a PC | |
| Ethernet 10/100 Mbit/s | LPD, RawIP printing, SOAP webservice, OPC UA, WebDAV, DHCP, HTTP/HTTPS, FTP/FTPS, TIME, NTP, Zeroconf, SNMP, SMTP, VNC |
| 1 x USB host on the operation panel for | Service Key or USB memory stick |
| 2 x USB host on the back side for | Service Key, USB memory stick, keyboard, barcode scanner, USB Bluetooth adapter, USB WLAN stick, external operation panel |
| USB WLAN stick 2.4 GHz 802.11b/g/n | |
| USB WLAN stick 2.4 GHz 802.11b/g/n + 5 GHz 802.11a/n/ac, Hotspot or Infrastructure Mode | |
| USB Bluetooth adapter | |
| Periphery connection USB host, 24 VDC | |
| Operating data | |
| Power supply | 100 – 240 VAC, 50/60 Hz, PFC | 24 VDC |
| Leistungsaufnahme | Standby 1,8 W / typical 45 W |
| Temperature / humidity Operation | +5 - 40°C / 10 - 85 %, not condensing |
| Temperature / humidity Storage | 0-60°C / 20 - 85 %, not condensing |
| Temperature / humidity Transport | –25 - 60°C / 20 - 85 %, not condensing |
| Approvals | CE, FCC Class A, ICES-3, cULus, CB, CoC Mexico, CCC, EAC, BIS, BSMI, KC-Mark, RCM |
