| Specifications |
| Printer Specifications |
| Print Method | Direct Thermal (Front Exit) |
| Print Speed | Up to 350 mm/sec |
| Print Resolution | SRP-F310II: 180 dpi (512 dots) |
| Print Width | SRP-F310II: Up to 72 mm |
| Sensor | Paper End, Paper Near End, Cover Open |
| Media Characteristics | |
| Media Type | Receipt |
| Media Width | 80 / 83 mm |
| Media Roll Diameter | Up to 105 mm |
| Media Thickness | 0.05 ~ 0.08mm |
| Supply Method | Easy Paper Loading |
| Physical Characteristics |
| Dimensions (W x D x H) | 154 x 203 x 148 mm (6.06 x 7.99 x 5.82 inch) |
| Weight | 2.00 kg (4.40 lbs.) |
| Electrical | EnergyStar Certified, External Power Supply Housed Internally (Adaptor 24V/2.5A, 50/60Hz |
| Drawer Port | 2 ports (Via y-type adaptor) |
| Performance Characteristics |
| NV Image Memory | 768 Kbytes (Mono) |
| Receive Buffer | 4Kbytes |
| User Define Buffer | 12Kbytes |
| Interface | Standard: USB V2.0 FS + Ethernet
Optional: USB V2.0 FS + Ethernet + Serial / Dual Serial / Parallel / WLAN¹ / Bluetooth² / Powered USB
----------------------------------------------------------------
WLAN¹: 802.11a/b/g/n(2.4G+5G)
Bluetooth²: V4.2 Classic / LE, Class 1, MFi certified
WLAN³: 802.11a/ac/b/g/n(2.4G+5G) USB dongle type (Optional) |
| Environment Characteristics |
| Temperature | Operating: 0 ~ 40℃ (32 ~ 104℉)
Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Humidity | Operating: 10 ~ 80%
RH Storage: 10 ~ 90% RH |
| Reliability |
| Thermal Print Head (TPH) | 250 km |
| Auto Cutter | 3 Million Cuts |
| *** Specified Paper | - TF50KS-E (Paper thickness: 65μm) : Nippon Paper industries Co., Ltd.
- PD 150R (Paper thickness: 75μm) : New Oji Paper Mfg, Co., Ltd
- PD 160R (Paper thickness: 75μm) : New Oji Paper Mfg, Co., Ltd.
- P350 (Paper thickness: 62μm) : Kansaki Specialty Paper, Inc. (USA) |
| Software |
| Emulation | BXL / POS |
| Driver / Utility | Windows Driver, OPOS / JPOS Driver, Linux / Mac CUPS Driver, Virtual COM USB / Ethernet Driver, Utility Program |
| SDK / Plugin | Android / iOS / Windows SDK, Linux SDK, Xamarin SDK, Chrome SDK, Cordova Plugin |
| Application | mPrint App (iOS), mPrint Server (Windows, iOS) |
| MDM | BIXOLON Profile Manager
- XPM™, XCM™ (Windows, Android) |
| Fonts / Graphics / Symbologies |
| Character Size | Font A: 12 x 24 Font B: 9 x 17 Font C: 9 x 24 KOR, CHN, JPN: 24 x 24 |
| Characters Per Line | SRP-F310II: Font A: 42 Font B, C: 56 KOR, CHN, JPN: 21 |
| Character Sets | Alphanumeric: 95 Expanded Graphics:128 x 35 page International: 32 |
| Graphics | Supporting User-Defined Fonts, Graphics, Formats, and Logos |
| Barcode Symbologies | 1D: Coda Bar, Code39, Code93, Code128, EAN-8, EAN-13, ITF, UPC-A, UPC-E
2D: Data Matrix, PDF417, QR Code |
| Accessories |
| Standard | 3 inch Partition (83 mm) |
| Optional | External buzzer, B-Melodist, USB A-B Cable 1.8m, USB to Serial cable, WLAN Dongle, Powered USB 0.5m, Powered USB 1.2m |
