| Physical Characteristics |
ZEBRA KC50 |
| Dimensions |
15 in: 15.17 in L x 9.43 in W x 1.51 in H
15 in: (385.2mm L x 239.4mm W x 38.3mm H)
22 in: 20.35 in L x 12.56 in W x 1.70 in H
22 in: (516.8mm L x 319.0mm W x 43.3mm H) |
| Weight |
15 in: 5.7 lbs (2.6kg)
22 in: 11.6 lbs (5.3kg) |
| Display |
22 in: 21.5 in. Full High Definition; 1080 x 1920; LED backlight; 300 NITS; optically bonded to touch panel
15 in: 15.6 in. Full High Definition; 1080 x 1920; LED backlight; 300 NITS; optically bonded to touch panel |
| Touch Panel |
2.0mm thick Alkali-Aluminosilicate chemically strengthened cover glass; fingerprint resistant anti-smudge coating; multi-mode capacitive touch with bare or gloved fingertip input or conductive stylus (sold separately) |
| Expansion |
MicroSD card supports up to 2 TB |
| Connectivity |
USB-C with DP ALT Mode for secondary display |
| Network Connections |
WLAN (Wireless Local Area Networks)
10/100/1000 Ethernet via RJ45 connector |
| Notifications |
Audible tone; haptic feedback; optional Z-Flex multi-color LED bar accessory, Power LED |
| Keypad |
On-screen keypad and enterprise keyboard |
| Audio |
Two microphones with noise cancellation; Dual 1W speakers |
| Buttons |
Power and volume up/down buttons |
| Interface Ports |
Ethernet RJ45; USB Type A 3.0 Superspeed Host Port; GPIO connector for future expansion with USB 2.0 Host Port |
| Scanner Support |
Support for external USB and Bluetooth Scanners |
| Mounting and Stands |
VESA 100 or VESA 75 mounting
Optional accessories: TD50 15-inch secondary display; Z-Flex SE4720 decoded scanner; Z-Flex Multi-Color LED light bar; desktop/floor/countertop stand accessories with support for printer box, height risers |
| Performance Characteristics |
|
| CPU |
Qualcomm® 5430 Octa Core chipset 2.1 GHz |
| Operating System |
Android; for supported Android versions, visit:
www.zebra.com/android-versions |
| Memory |
Up to 8 GB RAM/128 GB UFS Flash |
| User Environment |
|
| Operating Temp. |
+32F to +104F (0C to +40C) |
| Storage Temp. |
-40F to +158F (-40C to +70C) |
| Humidity |
5% to 95% non-condensing |
| Sealing |
IP65 per IEC 60529 |
| Vibration |
Sine: 4 g’s PK(5 Hz to 2 kHz)
Random: 6 g RMS (20 Hz to 2 kHz)
60 minute duration per axis, 3 axis |
Electrostatic
Discharge (ESD) |
+/- 15 kV air discharge; +/- 8 kV direct discharge;
+/- 8 kV indirect discharge |
| Power |
24 VDC Zebra PSU: PWR-BGA24V78W4WW
Power profiles: includes predefined or customized configurations for main display brightness, external display connection, speaker, Wi-Fi, Bluetooth, USB and GPIO connectors to meet different power allocations
Power over Ethernet: 30W to 90W PSE; IEEE 802.3at/bt; capable of receiving a maximum power of 71 watts from a compliant PoE power supply (support for Class 4 through 8) |
| Sensors |
|
| Motion Sensor |
3-axis gyroscope; 3-axis accelerometer |
| Data Capture |
|
Scanning
|
Optional SE4720 1D/2D decoded imager Z-Flex Accessory |
| Front Camera |
5 MP |
| Wireless LAN |
|
Radio
|
IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc; 2x2 MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6 GHz); Wi-Fi CERTIFIED 6™ (Wi-Fi 6E); Dual Band Simultaneous;
IPv4, IPv6 |
| Data Rates |
2.4 GHz: 802.11b/g/n/ax — 20 MHz — up to 286.8 Mbps;
5 GHz: 802.11a/n/ac/ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz — up to 2402 Mbps;
6 GHz: 802.11ax — 20 MHz, 40 MHz, 80 MHz, 160 MHz — up to 2402 Mbps |
| Operating Channels |
Channel 1-13 (2401-2483 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13;
Channel 36-165 (5150-5850 MHz): 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165;
Channel 1-233: (5925-7125 MHz)
Channel Bandwidth: 20, 40, 80, 160 MHz
Actual operating channels/frequencies and bandwidths depend on regulatory rules and certification agency.
|
| Security and Encryption |
WPA3 Enterprise 192-bit mode, GCMP256 — EAP-TLS; WPA3 Enterprise, AES-CCMP-128 — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP, EAP-PWD; WPA3 Personal (SAE), AES-CCMP-128; WPA/WPA2 Enterprise, TKIP and AES-CCMP-128; WPA/WPA2 Personal (PSK), TKIP and AES-CCMP-128; Enhanced Open (OWE), AES-CCMP-128; WEP 40 bit and 104 bit |
| Certifications |
Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 (Wi-Fi 6E); WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Enhanced Open; WMM (Wi-Fi Multimedia); WMM-Power Save; WMM-Admission Control; Voice-Enterprise; Wi-Fi Direct; Wi-Fi Agile Multiband; Wi-Fi QoS Management; Wi-Fi Optimized Connectivity; Passpoint |
| Fast Roam |
802.11r Fast BSS Transition; PMK Caching; Cisco CCKM; OKC |
| Wireless PAN |
|
| Bluetooth |
Class 2, Bluetooth v5.3 with Bluetooth Low Energy (BLE) |
| NFC |
Center of Display front facing; NFC ISO 14443 Type A and B; Mifare, FeliCa and ISO 15693 cards, NFC Forum tags 2,3,4,5; Host Card Emulation, Contactless Payment Support - Front Tap NFC for optimized contactless payment, VAS (Value Added Services) and Wallet support, Apple ECP1.0 and ECP2.0, Apple VAS and Google Smart Tap certified, VAS Library/SDK |
