Specification
|
Printer Specifications
|
• Print Method: Thermal Transfer & Direct Thermal • Resolution: 24 dots/mm (600 DPI) • Max. Print Speed: 152 mm (6”)/second • Max. Print Width: 104 mm (4.09”) • Max. Print Length: 2,540 mm (100”) • Processor: 32-bit RISC CPU • Memory: 512 MB Flash memory Memory / 512 MB SDRAM / microSD Flash memory card reader for Flash memory expansion, up to 32 GB • Printer Language: TSPL-EZTM (Compatible to EPL, ZPL, ZPL II) |
Media Specifications
|
• Media Type: Continuous, die-cut, black mark, fan-fold, notched (outside wound) • Media Width: 20 ~ 114 mm (0.78“ ~ 4.49“) • Media Thickness: 0.076 ~ 0.305 mm (2.99 ~ 12.01 mil) • Media Core Diameter: 76.2 mm (3”) |
Label Specification
|
• Label Roll Capacity: 203.2 mm (8“) OD • Label Length: 3 ~ 2,540 mm (0.1“ ~ 100“) |
Ribbon Specification
|
• Ribbon: 600 meter long, max. OD 90 mm,1“ core (ink coated outside/inside) • Ribbon Width: 40 ~ 115 mm |
Internal Fonts
|
• 8 alpha-numeric bitmap fonts • Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable font |
Barcodes
|
• 1D barcode: Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post • 2D barcode: PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Font and barcode rotation
|
• 0, 90, 180, 270 degree |
Interface
|
• RS-232 • USB 2.0 • Internal Ethernet, 10/100 Mbps • USB host * 2 (front side), for scanner or PC keyboard • GPIO + Centronics (dealer option) • Internal Bluetooth 4.0 (dealer option) • Slot-in 802.11 a/b/g/n wireless (user option) |
Operation Switch, Button
|
• 1 power switch, 6 operation buttons (Menu, Pause, Feed, Up, Down, Select) |
Power
|
Internal universal switching power supply • Input: AC 100-240V, 4-2A, 50-60Hz • Output: DC 5V, 5A; DC 24V, 7A; DC 36V, 1.4A; Total 243W
|
LCD
|
• 16 bits Color, 480 x 272 pixel, with back light, Resistive Touch Screen |
Sensors
|
• Gap transmissive sensor (position adjustable) • Black mark reflective sensor (position adjustable) • Head open sensor • Ribbon end sensor • Ribbon encode sensor • Media capacity sensor |
Real Time Clock
|
• Standard |
Environment Condition
|
• Operation: 5 ~ 40°C, 25 ~ 85% non-condensing • Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
Safety Regulation
|
• FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/safety, CCC, CB, BIS, EAC, ENERGY STAR® |
Environmental Concern
|
• Comply with RoHS, WEEE |
Accessories
|
• Windows labeling software CD disk • Quick start guide • USB cable • Power cord |
Physical Characteristics
|
• Enclosure: Die-cast based print mechanism and frame/Aluminum cover with large clear media view window • Width: 300mm (11.81″) • Height: 393mm (15.47″) • Depth: 510mm (20.08″) • Weight: 18 kg (39.68 lbs) |
User Options
|
• 802.11 a/b/g/n wireless module (slot-in) User options • KP-200 Plus series keyboard • KU-007 Plus programmable smart keyboard |
Dealer Options
|
• GPIO + Parallel interface • Internal Bluetooth 4.0 • Peel-off kit • Regular cutter (full cut guillotine cutter) • Heavy duty guillotine cutter |
Factory Options
|
• Internal rewinding kit (full roll) |
