| MODEL |
MB241 |
MB341 |
MB241T |
MB341T |
| Resolution |
203 dpi (8 dots/mm) |
300 dpi (12 dots/mm) |
203 dpi (8 dots/mm) |
300 dpi (12 dots/mm) |
| Print Method |
Direct thermal/Thermal transfer |
|
304.8mm (12") / second |
228.6mm (9") / second |
304.8mm (12") / second |
228.6mm (9") / second |
| Max. Print Width |
107mm (4.21") |
105.7mm (4.16") |
107mm (4.21") |
105.7mm (4.16") |
| Max. Print Length |
25,400mm (1000") |
11,430mm (450") |
25,400mm (1000") |
11,430mm (450") |
| Enclosure |
Die-cast based print mechanism/Metal cover with large clear media window |
| Physical Dimension |
248mm (W) x 274mm (H) x 436mm (D)
9.76" (W) x 10.79" (H) x 17.17" (D) |
| Weight |
9.1kg (20.06lbs) |
| Label Roll Capacity |
203.2mm (8") O.D., 1" - 3" I.D. core |
| Ribbon |
450m with 1" ribbon core I.D., ink coated outside or inside |
| Ribbon Width |
40mm - 110mm (1.6" - 4.3") |
| Processor |
32-bit RISC CPU |
| Memory |
• 256 MB Flash memory
• 256 MB SDRAM |
| Interface |
• RS-232
• USB 2.0
• Internal Ethernet, 10/100 Mbps
• USB host, for scanner or PC keyboard
• GPIO (dealer option)
• Internal Bluetooth (dealer option)
• Internal Bluetooth 5.0 MFi (factory option)
• Slot-in Wi-Fi 802.11 a/b/g/n/ac with Bluetooth
5.0 combo module (dealer option) |
| Power |
• Internal universal switching power supply
• Input: AC 100 - 240V, 2.0A, 50 - 60Hz
• Output: DC 24V, 3.75A, 90W |
| LED/LCD |
• 2.3" color LCD
• 1 LED (with 2 LEDs: green, red) |
• 3.5" color touch LCD
• 1 LED (with 2 LEDs: green, red) |
Operation Switch,
Button |
• 1 power switch
• 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right) |
| Sensors |
• Gap transmissive sensor (position adjustable)
• Black mark reflective sensor (position
adjustable)
• Ribbon encoder sensor
• Ribbon end sensor
• Head open sensor |
| Real Time Clock |
Standard |
| Internal Fonts |
• 8 alpha-numeric bitmap fonts
• Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable fon |
| Barcode |
• 1D barcode
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked,
GS1 DataBar, Code 11, China Post
• 2D barcode
PDF-417, Micro PDF 417, Maxicode, DataMatrix, QR code, Aztec, TLC 39, RSS |
| Font & Barcode Rotation |
0, 90, 180, 270 degree |
| Printer Language |
TSPL-EZD (EPL, ZPL, ZPL II, DPL) |
| Media Type |
Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media Width |
20mm - 120mm (0.8" - 4.7") |
| Media Thickness |
0.06mm - 0.28mm (2.36mil - 11mil) |
| Media Core Diameter |
25.4mm - 76.2mm (1" - 3") |
| Label Length |
5mm - 25,400mm
(0.2" - 1000") |
5mm - 11,430mm
(0.2" - 450") |
5mm - 25,400mm
(0.2" - 1000") |
5mm - 11,430mm
(0.2" - 450") |
| Environment Condition |
• Operation: 0°C to 40°C (32°F to 104°F), 25% - 85% non-condensing
• Storage: -40°C to 60°C (-40°F to 140°F), 10% - 90% non-condensing |
| Safety Regulation |
CB, FCC Class A, CE Class A, UKCA, RCM Class A, cTUVus, TÜV, IC Class A, NOM, VCCI, CCC, BIS, KC, BSMI,
EAC, ENERGY STAR® |
| Environmental Concern |
Comply with RoHS, WEEE |
| Accessories |
• Quick start guide
• USB cable
• Power cord |
| Factory Option |
Internal Bluetooth 5.0 MFi |
|
|
|
| Dealer Option |
• Peel-off kit
• Regular guillotine cutter (full cut)
• 5" O.D. internal rewinder kit
• GPIO
• Linerless tear-off kit
• Linerless cutter kit
• Slot-in Wi-Fi 802.11 a/b/g/n/ac with Bluetooth
5.0 combo upgrade kit
• Internal Bluetooth 5.0 module** |
| User Option |
• Slot-in Wi-Fi 802.11 a/b/g/n/ac with Bluetooth 5.0 combo module (for device with slot-in housing)
• KP-200 Plus keyboard display unit
• Universal cutter tray |
