| Specification |
| Resolution |
8 dots/mm (203 DPI) |
| Printing method |
Thermal Transfer & Direct Thermal |
| Max. print speed |
203 mm (8")/second |
| Max. print width |
108 mm (4.25") |
| Max. print length |
25,400 mm (1000") |
| Enclosure |
Die-cast based print mechanism/Metal cover with large clear media view window |
| Physical dimension |
248 mm (W) x 274 mm (H) x 436 mm (D) 9.76” (W) x 10.79” (H) x 17.17” (D) |
| Weight |
9 kg (19.84 lbs) |
| Label roll capacity |
203.2 mm (8“) O.D |
| Ribbon |
450 m long, max. O.D. 81.3 mm, 1“ core (ink coated outside or inside) |
| Ribbon width |
40 mm ~ 110 mm (1.6” ~ 4.3”) |
| Processor |
32-bit RISC CPU |
| Memory |
• 128 MB Flash memory • 64 MB SDRAM |
| Interface |
• RS-232
• USB 2.0
• Internal Ethernet, 10/100 Mbps
• USB host, for scanner or PC keyboard
• GPIO (dealer option)
• Internal Bluetooth 4.2 (dealer option)
• Slot-in 802.11 a/b/g/n wireless (dealer option) |
| Power |
• Internal universal switching power supply
• Input: AC 100-240V, 2.0A, 50-60Hz
• Output: DC 24V, 3.75A, 90W |
| LED/LCD |
• 4 intuitive icon indicators
• 1 status indicator |
| Operation switch, button |
• 2 buttons (Pause, Feed) |
| Sensors |
• Gap transmissive sensor (position adjustable)
• Black mark reflective sensor (position adjustable)
• Ribbon encoder sensor
• Ribbon end sensor
• Head open sensor |
| Real time clock |
Standard |
| Bar code |
• 1D bar code Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post
• 2D bar code PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Label length |
5 ~ 25,400 mm (0.2" ~ 1000") |
| Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
| Safety regulation |
FCC Class A, CE Class A, RCM Class A, cTUVus, CCC, BIS, TÜV, KC, BSMI, EAC, ENERGY STAR® |
| Environmental concern |
Comply with RoHS, WEEE |
