| Technical specifications |
|
| Data Capture |
|
| 1D |
All major 1D symbologies, including EAN-8, EAN-13, UPC-E, UPC-A, Code 128, UCC/EAN128, I2Of5, ITF-14, ITF-6, Matrix 25, CodaBar, Code 39, Code 93, ISSN, ISBN, Industrial 25, Standard 25, Plessey, Code11, MSI-Plessey, UCC/EAN Composite, GS1 Databar, Code 49, Code 16K.
|
| 2D |
All major 2D symbologies, including PDF 417, QR Code, Micro QR, Data Matrix, Aztec, Maxicode, Chinese Sensible Code, GM Code, Micro PDF417 Code, Code One.
|
| Image Sensor |
640x480 CMOS |
| Illumination |
White LED |
| Depth of Field EAN 13 (13mil) |
25mm-110mm |
| Depth of Field PDF417 (6.67mil) |
35mm-45mm |
| Depth of Field DataMatrix (10mil) |
35mm-50mm |
| Depth of Field QR (15mil) |
0mm-90mm |
| Field of View Horizontal |
68° |
| Field of View Vertical |
51° |
| Scan Angle Roll |
360° |
| Scan Angle Pitch |
±40° |
| Scan Angle Skew |
±45° |
| Minimal Print Contrast |
30% |
| Physical |
|
| Current @ 3.3VDC Operating |
141mA |
| Current @ 3.3VDC Standby |
93mA |
| Current @ 5VDC Standby |
51 mA |
| Dimensions (mm) |
61.5(W)x65.5(D)x31.9(H)mm (max)
|
| Input Voltage |
12-pin FPC connector: 3.3-5VDC±5% 4-pin box connector: 3.3-5VDC±5%
|
| Interfaces |
|
| Notifications |
Beeper, Green LED Indicator
|
| Power Consumption |
3.3VDC: 466 mW 5VDC: 755 mW (typical)
|
| Weight |
33g |
| Environmental |
|
| Ambient Light |
0~100,000lux (natural light)
|
| Operating Temperature |
-40°C to 60°C |
| Storage Temperature |
-40°C to 75°C |
| Humidity |
5% to 95% (non-condensing)
|
| Accessories |
|
| Standard |
180mm flexible flat cable (FFC), EVK2037
|
| Optional |
USB cable, RS-232 cable with DC5V plug adapter
|
| Software |
|
| Configuration Tools |
EasySet |
| Certifications |
|
| Hardware |
CE EMC Class B, FCC Part15 Class B
|
| Warranty |
|
| Standard |
2 years |
