| PRINT SPECIFICATIONS |
PRPDUCT NAME
|
TM-T82III |
| PRINT METHOD |
Line Thermal |
| DOT DENSITY |
203 dpi x 203 dpi |
| PRINT SPEED |
Max. 250mm/s |
PRINT WIDTH
(80mm paper width) |
72±0.5mm |
PRINT WIDTH
(58mm paper width) |
52.5±0.5mm |
| FONTS |
12x24 (Font A), 9x17 (Font B) |
COLUMN CAPACITY
(80MM PAPER WIDTH) |
48 (Font A), 64 (Font B) |
COLUMN CAPACITY
(58MM PAPER WIDTH) |
35 (Font A), 46 (Font B) |
| CHARACTER SIZE (mm) |
1.25x3 mm (Font A), 0.88x2.13 mm (Font B) |
| CHARACTER SET |
Alphanumeric 95, International character 18 set, Graphics 128x43 page including user-defined page |
| CHARACTERS |
ANK, Simplified Chinese |
| BARCODE |
UPC-A, UPC-E, JAN8/EAN 8, JAN13/EAN13, Code39, Code93, Code128, ITF, CODABAR(NW-7), GS1-128, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar Expanded |
| 2-DIMENTIONAL SYMBOLS |
PDF417, QR code, Maxi Code, Datamatrix, Aztec, Two-dimensional GS1 DataBar, Composite Symbology |
PAPER SIZE
(80mm paper width) |
79.5 ± 0.5mm |
PAPER SIZE
(58mm paper width) |
57.5 ± 0.5mm |
| DIAMETER |
83[mm] |
| PAPER THICKNESS |
48-80 μm |
| AUTO CUTTER |
Partial cut (cutting with one point in left edge left uncut) |
| SENSORS |
Roll paper end / Roll paper near-end / Cover open |
| MCBF |
60 million lines |
| MTBF |
360,000 hours |
| AUTO CUTTER LIFE |
1.5 million cuts |
| HEAD LIFE |
150km, 15 million lines |
| INTERFACES |
USB 2.0+RS-232C;
USB 2.0(capped)+Ethernet;
USB 2.0+Parallel |
| D.K.D. FUNCTIONS |
2 drivers |
| AC ADAPTER |
AC adapter C1 |
| POWER SOURCE |
DC 24V±5% |
| POWER CONSUMPTION |
Approx 0.80W (Stand-by)
Approx 29.5W (Operating) |
| TEMPERATURE |
Operation 5-45℃ / Storage -10-50℃ |
| HUMIDITY |
Operation 10-90% / Storage 10-90% |
| NOISE LEVEL |
Approx. 55 dB (bystander position) |
| OVERALL DIMENSIONS |
140mm (W) x 199mm (D) x 146mm (H) |
| WEIGHT |
1.7Kg |
| COLOUR |
EBCK |
| INSTALLATION |
Horizontally / Vertically / Wall-mounted |
| BUZZER |
Unsupported |
| OPERATING SYSTEMS |
Windows, MacOSX, iOS, Android, Linux |
| DATA BUFFER |
Selectable as 45 bytes or 4 KB |
| WHAT'S IN THE BOX |
Roll paper, User's manual, AC adapter, AC cable, USB cable, Wall hanging bracket, Screws for wall hanging bracket, 58mm-width paper guide plate, Power switch cover, Power switch waterproof cover, Rubber feet for vertical installation |
| OPTIONS / ACCESSORIES |
External buzzer OT-BZ20, Wi-Fi dongle OT-WL06 |
| PART NUMBER |
C31CH51541 - TM-T82III USB + Serial EDG
C31CH51542 - TM-T82III USB + Ethernet (Lan) EDG
C31CH51543 - TM-T82III USB + Parallel EDG
|
