| Specifications |
| PHYSICAL CHARACTERISTICS |
| Dimensions |
- 8.0 in. H x 3.7 in. W x 5.2 in. D
- 20.3 cm H x 9.4 cm W x 13.2 cm D
|
| Weight |
|
| Input Voltage Range |
4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply |
| Current |
Operating current at nominal voltage (5.0V): DS9908: 321 mA (typical) |
| |
Standby current (idle) at nominal voltage (5.0V): DS9908: 70 mA (typical) |
| Color |
Midnight Black |
| Supported Host Interfaces |
USB Certified3, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 |
| Keyboard Support |
Supports over 90 international keyboards |
| Electronic Article Surveillance |
Compatible with Checkpoint EAS deactivation system |
| User Indicators |
Direct Decode Indicator, Good Decode LEDs, Speaker (adjustable tone and volume) |
| PERFORMANCE CHARACTERISTICS |
| Swipe Speed (HandsFree) |
Up to 240 in./610 cm per second for 13 mil UPC in optimized mode |
| Light Source |
Aiming Pattern: Circular 617nm Amber LED |
| Illumination |
(2) 645nm Red LEDs |
| Imager Field of View |
48° H x 30.6° V Nominal |
| Image Sensor |
1280 x 800 pixels |
| Minimum Print Contrast |
16% minimum reflective difference |
| Skew Tolerance |
+/- 60° |
| Pitch Tolerance |
+/- 60° |
| Roll Tolerance |
0° - 360° |
| IMAGING CHARACTERISTICS |
| Graphics Format Support |
Images can be exported as Bitmap, JPEG or TIFF |
| Image Quality (A4 Document) |
116 PPI on an 8.3 x 11.7 in./21.0 x 29.7 cm document @ 8.0 in./ 20.3 cm |
| ENVIRONMENTAL |
| Operating Temperature |
32.0° to 122.0° F / 0.0° to 50.0°C |
| Storage Temperature |
-40.0° to 158.0° F / -40.0° to 70.0°C |
| Humidity |
5% to 95% RH, non-condensing |
| Drop Specification |
Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete |
| Tumble Specification |
Designed to withstand 2,000 tumbles in 1.5 ft. /0.5 m tumbler4 |
| Environmental Sealing |
IP52 |
| Electrostatic Discharge (ESD) |
ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect |
| Ambient Light Immunity |
0 to 10,000 Foot Candles / 0 to 107,600 Lux |
| REGULATORY |
| Environmental |
EN 50581:2012 |
| Electrical Safety |
- IEC 62368-1 (ed.2)
- EN 62368-1:2014/AC:2015
|
| LED Safety |
- IEC 62471:2006 (Ed.1.0)
- EN 62471:2008 (LED)
|
| EMI/RFI |
- EN 55032:2012/AC:2013 (Class B)
- EN 55032:2015/AC:2016 (Class B)
- EN 55024:2010
- EN 55024:2010/A1:2015
- EN 55035:2017
- EN 61000-3-2:2014 (Class A)
- EN 61000-3-3:2013
- 47 CFR Part 15, Subpart B, Class B
- ICES-003 Issue 6, Class B
|
| SYMBOL DECODE CAPABILITY |
| 1D |
Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
| 2D |
PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes |
| OCR |
OCR-A, OCR-B, MICR, US Currency |
| Digimarc |
Digimarc barcodes |
| Refer to Product Reference Guide for a complete list of symbologies. |
| Minimum Element Resolution |
Code 39 - 3.0 mil Code 128 - 3.0 mil DataMatrix - 6.0 mil QR Code - 6.0 mil |
