| Specifications |
| Printer Specifications |
| Print Method |
Direct Thermal |
| Print Speed |
Up to 5 ips (127 mm/sec - Label)
Up to 4 ips (102 mm/sec - Linerless)
12.5% pattern |
| Print Resolution |
203 dpi |
| Print Width |
Up to 72 mm |
| Sensing |
Paper End
Gap
Black Mark
Paper Cover Open |
| Media Characteristics |
| Media Type |
Liner, Linerless (Optional) |
| Media Width |
80 mm
Optional 58 / 62 / 66 / 70 / 74 mm |
| Media Roll Diameter |
Up to 49 mm |
| Media Thickness |
0.07 ~ 0.19mm |
| Supply Method |
Easy Paper Loading |
| Physical Characteristics Dimensions (W x L x H) |
105 x 126 x 58 mm
(4.14 x 4.97 x 2.29 inch) |
| Weight |
Including battery: 385 g (0.85 Ibs.)
Paper : 133 g (0.29 lbs.) |
| Electrical |
7.3 V Li-ion, 2850 mAh (Nominal),
Rechargeable Charging time: Up to 4 hrs
EnergyStar Certified |
| Performance Characteristics |
| Memory |
128 MB SDRAM, 256 MB Flash
256 MB SDRAM, 512 MB Flash (Optional) |
| Interface |
Standard: USB V2.0 HS + Serial
Optional: USB V2.0 HS + Serial + Bluetooth /
WLAN
---------------------------------------------------------------
Bluetooth: V4.1 Classic & LE
WLAN: 802.11a/b/g/n (Infrastructure, Ad-hoc,
Wi-Fi Direct, SoftAP)
- WEP40/104, WPA1/2 (PSK, EAP)
---------------------------------------------------------------
* Easy Bluetooth Pairing™ via NFC |
| Environment Characteristics |
| Temperature |
Operating: -15 ~ 50℃ (5 ~ 122℉)
Storage: -30 ~ 70℃ (-22 ~ 158℉) |
| Humidity |
Operating: 10 ~ 80% RH |
| Sealing |
IP54 |
| Drop Rate |
1.8 m (6 ft.) |
| Software |
| Emulation |
SLCS, BPL-Z™, BPL-C™ |
| Driver / Utility |
Windows Driver (Europlus / Seagull), Linux / Mac CUPS Driver, Virtual COM USB Driver, Utility Program, LabelArtist-II™, Bartender UL, OPOS / JPOS Driver, SAP® Device Driver, Network Auto Installer |
| SDK / Plugin |
Android / iOS / Windows SDK, Linux SDK,
Chrome SDK, Xamarin SDK, Cordova Plugin |
| Application |
Label Artist™ Mobile (Android, iOS)
mPrint App (iOS) |
| Fonts / Graphics / Symbologies |
| Fonts |
10 SLCS / One SLCS / 16 BPL-Z™ / One BPL-Z™ / 7 BPL-C™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics |
Supporting user-defined fonts, graphics, formats, layouts and logos |
| Barcode Symbologies |
1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC / EAN extensions, UPC-A, UPC-E, IMB
2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
| Accessories |
| Standard |
Belt Clip, Battery Pack, Battery Charger, Power Cord |
| Optional |
Belt Strap, Shoulder Strap, Single Battery Cradle, Quad Battery Charger, Vehicle Charger, Serial / USB Cable, Vehicle-Holder, RAM mount Vehicle-Holder, Case, Protective Case, Detachable Media Holder |
